Characteristics
A. Host part
laser lamp on paper tubes
B. Material discharge section
1. The feeding mechanism is a connected feeding rack
2. shaftless hydraulic uploading raw materials
3. adjustable deflection rod can be adjusted through a handwheel
4. Magnetic powder brake for unwinding
5. Edge correction material by PAUSOURCE or BST brand (other brands can be chosen separately)
C. Material receiving section
1. with 3-inch pneumatic inflation differentrial shafts for unwind 2 Pcs
2. The locking method is controlled by method
3. The winding tension by electrician valve
4. circular knives or Straight knives 10 pcs standard
Optional
5. waste blowing edge Trimming winder is Optional
6. Rotary subframe for unloading finished roll is Optional
D. Electrical parts
1. The host adopts a frequency converter
2. Main machines, 1 SERVO motor
3. Winding using 2 frequency converters
4. 2 SERVO motors for rewind
5. PLC control
Using imported PLC to achieve precise and stable control functions only requires input of raw material thickness, broadband diameter, and speed.
All subsequent tasks are automatically calculated by the computer.
